This Standard covers pressure-temperature ratings, materials, dimensions, tolerances, marking, testing, and methods of designating openings for pipe flanges and flanged fittings. Included are:
This Standard is limited to:
- flanges with rating class designations 150, 300, 400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24 and flanges with rating class designation 2500 in sizes NPS 1/2 through NPS 12, with requirements given in both metric and U.S. Customary units with diameter of bolts and flange bolt holes expressed in inch units
- flanged fittings with rating class designation 150 and 300 in sizes NPS 1/2 through NPS 24, with requirements given in both metric and U.S. Customary units with diameter of bolts and flange bolt holes expressed in inch units
- flanged fittings with rating class designation 400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24 and flanged fittings with rating class designation 2500 in sizes 1/2 through NPS 12 that are acknowledged in Nonmandatory Appendix E in which only U.S. Customary units are provided
This Standard is limited to:
- flanges and flanged fittings made from cast or forged materials
- blind flanges and certain reducing flanges made from cast, forged, or plate materials
- Also included in this Standard are requirements and recommendations regarding flange bolting, gaskets, and joints.
ASME B16.5-2009 History
ASME B16.5-2017
$136.00 $273.00
ASME B16.5-2009
$121.00 $242.00
ASME B16.5-2003
$113.00 $226.00
ASME B16.5-1996
$63.00 $126.00
